Broadcasting Signal Monitoring

Today, many major TV and radio stations share common antenna sites often with complex combining networks that demand monitoring and protection beyond a simple remote control. To protect these significant investments, broadcasters need a proactive solution to not only provide next level of monitoring, logging and control, but a comprehensive VSWR system for maximum protection. While most modern transmitter have VSWR protection they only protect the transmitter, leaving the rest of the system exposed to costly damage.

Stellar Eclipse with our exclusive VSWR Sentinel is designed to protect and monitor these systems by constantly monitoring the VSWR on all inputs and outputs to the combiner system, refreshing these values many times every second. Anytime a VSWR is detected that exceeds a preset threshold, hard relay interlock relays are controlled that can open interlocks on connected transmitters. RF power is then removed from the system when an unsafe condition exists, thereby saving the systems from costly damage.

Affordable Site Monitoring and VSWR protection for single or multiplexed TV and FM transmission systems

• Modular design so the system can grow as you do
• Carefully tracks transmission line gas pressure with options for gas flow rate monitoring
• Proactively monitors dehydrator/nitrogen generator run times to prevent costly surprises
• Flexible Motorized RF switch control and status built in eliminating extra costs
• Simple connections for building security, electrical consumption, and tower light monitoring

Proven reliability protects your investment

• On-the-air protecting hundreds of stations and hundreds of millions of dollars of revenue
• Ideal for new builds or a simple upgrade to existing installations
• Easy bypass of critical transmitter interlocks for maintenance
• Fail safe operation keeps your stations on the air during a power loss to the monitoring system

Flexible cloud based remote access

• Secure SSL and password protected Web Access to real time and historical data
• Limitless user accounts for web data access
• Secure cloud Based data storage for all parameters
• Provides alarms via text message and email for any parameters that fall out of tolerance

Comprehensive VSWR Sentinel for maximum protection

• Opens transmitter interlocks within 100 milliseconds of a VSWR being detected above the desired threshold
• 3 Strikes automatic reset logic included
• Interlocking of RF patch panels and lockout/tag-out switches
• Secure key-switch to lockout RF during tower climbing activities

On-site installation, calibration and training included
